Wear laboratory coat
Instructs the reader to wear a laboratory coat.
Understanding this sign
Blue circular signs communicate an action, such as wearing eye protection or following a specified procedure.
A pictogram does not select the grade of PPE or explain a complete procedure. Use the task-specific instructions.
More Than a Uniform
M059 makes the laboratory coat a posted requirement rather than a custom. The coat's job is twofold: it is a sacrificial layer between splashes, spills, and dusts and the wearer's skin and street clothes, and it is a contamination boundary that stays inside the lab so whatever lands on it does not ride home on a sweater. ISO 7010 added a dedicated code for it because 'protective clothing' (M010) was too broad for the specific garment, behaviors, and removal rules that laboratory work involves.
The sign appears at chemistry, biology, and clinical labs, pharmaceutical QC suites, teaching laboratories, and pilot plants. In teaching settings it does double duty as an admission rule — no coat, no bench work — which is often the first PPE discipline students encounter. The pictogram, a figure in a knee-length coat, reads instantly in that context.
US Regulatory Context: The Chemical Hygiene Plan
In American laboratories using hazardous chemicals, coat requirements flow from the OSHA laboratory standard at 29 CFR 1910.1450, which obliges the employer to maintain a Chemical Hygiene Plan specifying the control measures — including protective apparel — for the procedures in use. The plan, typically administered by a Chemical Hygiene Officer, is where 'lab coats required in all wet-chemistry spaces' becomes an enforceable rule, and M059 signage at lab doors is how that rule meets the people it governs.
Biological and clinical work brings parallel drivers: bloodborne pathogens requirements and biosafety-level practices both call for protective gowns or coats that are removed before leaving the work area and never laundered at home. Institutional laundering or disposal is a compliance point in its own right — a contaminated coat in a domestic washing machine defeats the boundary the garment exists to create.
Cotton, Poly-Cotton, or Flame-Resistant
Coat selection is where many labs under-deliver on the sign. Standard poly-cotton coats handle incidental splash and dirt but melt and burn when ignited, which makes them a liability around open flames and reactive chemistry. Work with pyrophoric reagents such as tert-butyllithium — infamous in laboratory-safety case history — and with large volumes of flammable solvents calls for flame-resistant coats of inherently FR fibre or treated cotton, a distinction many universities wrote into policy over the past two decades.
Fit and habits complete the protection: sleeves down to the wrist, coat snapped or buttoned closed, and quick-release snap closures preferred so a burning or soaked coat can be shed in seconds. A coat worn open over bare forearms satisfies the camera but not the hazard. Sites that specify coat classes by room — general purpose here, FR in the synthesis lab — should say so on or beside the M059 sign.
Boundary Rules and Sign Placement
Post M059 at each laboratory entrance, at the coat rack or gowning point, and, where relevant, at boundaries between lab zones with different coat requirements. The complementary rule deserves equal prominence: coats off before offices, break rooms, toilets, and cafeterias. Some facilities express this with a prohibition-style notice at the lab exit, and hooks placed at the door make the right behavior the easy one in both directions.
M059 rarely stands alone. Bench chemistry typically pairs it with eye protection signage and often gloves, so a small panel of mandatory signs at the door communicates the full entry standard at once. Keep the panel truthful: if the coat rule genuinely applies only during active chemical work and not in the write-up area, zone the signs accordingly, because a rule posted wider than it is enforced erodes every sign on the wall.
Where you will see M059
Chemistry, biology, and clinical labs, pharmaceutical QC suites, teaching laboratories, and pilot plants sign each entrance, gowning point, and boundary between zones with different coat classes, specifying flame-resistant coats where pyrophorics and bulk flammable solvents are handled. Under OSHA's 1910.1450 laboratory standard, the sign is where the Chemical Hygiene Plan's protective apparel rule meets the people it governs.
Common questions about M059
Are lab coats required by OSHA?
Not by a blanket rule, but effectively yes in most labs using hazardous chemicals. The OSHA laboratory standard at 29 CFR 1910.1450 requires a Chemical Hygiene Plan identifying the protective apparel needed for the work, and the general PPE standard requires body protection wherever the hazard assessment finds skin exposure. Once the plan specifies coats, wearing them is enforceable, and M059 signage marks where.
When do I need a flame-resistant lab coat?
When the work involves pyrophoric reagents, open flames near flammables, or significant fire risk from reactive chemistry or large solvent volumes. Ordinary poly-cotton coats can ignite and melt onto the skin, so FR coats made of inherently flame-resistant fibre or treated cotton are specified for that work. Your Chemical Hygiene Plan or institutional PPE policy should define which rooms and procedures require the FR class.
Can I wear my lab coat in the office or cafeteria?
No. The coat is a contamination boundary as much as a splash barrier, and wearing it into eating or public areas transports whatever it has absorbed. Standard practice is coat on at the lab entrance, coat off at the exit, with institutional laundering rather than home washing. Many labs post a removal reminder at the door opposite the M059 sign.
What is the difference between M059 and M010?
M010 is the general protective-clothing sign covering everything from coveralls to chemical suits; M059 names the laboratory coat specifically. Use M059 for lab entrances where the coat is the required garment, and reserve M010 for areas where a different or higher grade of body protection — a splash suit, arc-rated clothing, a gowning regime — is what the assessment demands.
Reference details
| Symbol code | M059 |
|---|---|
| Sign family | ISO Mandatory Signs |
| Standard reference | ISO 7010:2019 / ISO 3864-1 ISO Online Browsing Platform: M059 |
| Screen color reference | #0000FF. Screen colors are not a production color specification. |
| Download formats | SVG reference artwork; a 1024 × 1024 pixel PNG conversion on a white canvas. |
| Record date | · How to interpret our dates |
| Page updated |
Choosing a physical sign size
Download dimensions are not installation dimensions. Select sign size, material, placement, and lighting using the applicable standard and the actual viewing conditions. Chemical label sizing follows its own rules. Read the artwork and sizing guide.
Sources and artwork credits
- Artwork source
- Wikimedia Commons file page
- Creator credited by source
- Clemenspool
- License
- CC0
- Source metadata checked
SVG files are local reference copies. PNG files are raster conversions. Check the linked file history and license terms before reuse; a source-metadata check is not certification of the artwork or a workplace installation.
