Fixed fire extinguishing bottle
Identifies a fixed fire extinguishing bottle.
Understanding this sign
Red square or rectangular signs identify fire equipment and manual alarm points.
Finding equipment does not mean it is suitable or safe to use. Follow your training and the site emergency procedure.
One Bottle, One Sign
F013 marks a fixed fire extinguishing bottle: a single permanently installed cylinder of extinguishing agent, plumbed to protect a specific enclosure or to perform a specific function within a larger system. It is the narrowest referent in the fixed-system family — not the manifolded cylinder bank of F008, not the whole installation of F012, but an individual bottle mounted in place.
Such bottles are everywhere once you look for them: a CO2 cylinder dedicated to a galley exhaust duct or paint locker, a pilot or actuation bottle that fires a bigger system, a suppression cylinder inside a machine enclosure or engine compartment. Because a lone bottle is small and easily hidden behind panels or in a recess, the sign frequently is the only visible evidence that the protection exists.
Typical Installations Afloat and Ashore
On vessels — the setting these harmonized symbols came from — individual fixed bottles commonly protect small high-risk enclosures where running pipework from the main CO2 battery would be disproportionate: paint stores, flammable liquid lockers, emergency generator rooms, and galley duct systems. The bottle sits at or near the space it serves, with a local release, and F013 on the adjacent bulkhead or access panel tells crew and surveyors what the cylinder is and why it is there.
Ashore, the equivalent appears in local application systems: a bottle protecting a CNC machine cabinet, an electrical cubicle, a fume cupboard, or a vehicle engine bay. Marking these matters for more than firefighting — a technician opening an enclosure needs to know a charged extinguishing cylinder and its detection tubing live inside before disturbing them.
Maintenance, Inspection, and Sign Discipline
A fixed bottle carries the same service obligations as any pressure vessel in fire duty: periodic checks of charge weight or pressure, inspection of the release head and any detection line, and eventual hydrostatic retest. Distributed single bottles are precisely the assets that fall off maintenance schedules because no one passes them daily; a consistently applied F013 sign gives inspection rounds a visible checklist item at each protected enclosure.
Keep the sign at the bottle's actual position, updating it when equipment is relocated or decommissioned. An orphaned F013 sign implies protection that no longer exists, and an unmarked bottle invites accidental damage during unrelated work. Where the bottle hides behind an access panel, put the sign on the panel face so the message survives the concealment.
Where you will see F013
On vessels, individual bottles protect paint stores, flammable liquid lockers, emergency generator rooms, and galley exhaust ducts, with F013 on the adjacent bulkhead or access panel for crew and surveyors. Shore-side equivalents guard CNC machine cabinets, electrical cubicles, fume cupboards, and vehicle engine bays, where the sign also warns technicians that a charged cylinder and its detection tubing live inside before they open the enclosure.
Common questions about F013
What does the ISO 7010 F013 sign indicate?
The position of a single, permanently installed extinguishing agent cylinder serving a specific enclosure or function — such as a paint locker CO2 bottle, a galley duct cylinder, or a suppression bottle inside a machine cabinet. It is the individual-bottle counterpart to the F008 battery sign.
How is F013 different from F008?
F008 marks a battery: a bank of manifolded cylinders, typically in a dedicated room, feeding a large fixed system. F013 marks one individual bottle installed at or near the small space it protects. The scale of the hardware, not the agent, is what separates the two signs.
Why sign a bottle that is hidden inside an enclosure?
Because the people most likely to encounter it are technicians opening the enclosure for other work. The sign warns that a charged cylinder, its release head, and detection tubing are inside, prevents accidental damage or unintended discharge, and gives fire equipment inspections a visible marker for an asset that would otherwise be forgotten.
Do fixed extinguishing bottles need regular servicing?
Yes. Like other fire-duty pressure cylinders they need periodic charge or weight checks, inspection of release mechanisms and detection lines, and hydrostatic retesting at intervals set by the applicable rules and the manufacturer. Scattered single bottles are the easiest fire assets to miss, which is one practical reason to sign each location.
Reference details
| Symbol code | F013 |
|---|---|
| Sign family | ISO Fire Equipment Signs |
| Standard reference | ISO 7010:2019 / ISO 3864-1 ISO Online Browsing Platform: F013 |
| Screen color reference | #FF0000. Screen colors are not a production color specification. |
| Download formats | SVG reference artwork; a 1024 × 1024 pixel PNG conversion on a white canvas. |
| Record date | · How to interpret our dates |
| Page updated |
Choosing a physical sign size
Download dimensions are not installation dimensions. Select sign size, material, placement, and lighting using the applicable standard and the actual viewing conditions. Chemical label sizing follows its own rules. Read the artwork and sizing guide.
