Fixed fire extinguishing battery
Identifies a fixed fire extinguishing battery.
Understanding this sign
Red square or rectangular signs identify fire equipment and manual alarm points.
Finding equipment does not mean it is suitable or safe to use. Follow your training and the site emergency procedure.
What F008 Marks: The Cylinder Bank, Not the System
F008 identifies where a fixed fire extinguishing battery is located — the bank of pressurized cylinders that stores the extinguishing agent for a fixed system. The pictogram shows a row of connected cylinders on the red square common to all ISO 7010 F-series signs. On ships and in industrial plants, this typically means the CO2 room or inert gas cylinder space: a dedicated compartment holding dozens or even hundreds of manifolded bottles piped to machinery spaces, cargo holds, or other protected areas.
The distinction from its siblings matters. F008 points to the agent storage bank itself; F012 marks a space that contains or is protected by the fixed installation; F013 flags an individual extinguishing bottle; F014 shows where the system is triggered from. A responder tracing a CO2 system during an incident may need all four, and mixing them up sends people to the wrong compartment at the worst possible moment.
Marine Origins and Where the Sign Appears
Like most of the fixed-system group in ISO 7010, F008 was harmonized from symbols long used in maritime signage, and shipboard use remains its natural home. Vessels with CO2 total-flooding protection for the engine room or cargo spaces carry a cylinder bank in a dedicated room, and the door to that room is where this sign belongs — visible to crew, port-state inspectors, and shore firefighters who board unfamiliar ships.
Ashore, the same sign suits gaseous-suppression cylinder rooms serving turbine enclosures, transformer vaults, archives, and data centers, wherever the agent bottles are grouped in a separate space rather than inside the protected room. Fire brigades attending an industrial site want to locate the battery quickly, both to confirm whether the system has discharged and to isolate it before entry.
Why the Battery Room Itself Needs Identification
A CO2 or inert gas cylinder room is a hazard in its own right. A leaking cylinder or a slow manifold release can displace oxygen in the compartment, so many operators pair F008 on the door with asphyxiation warnings, ventilation-before-entry procedures, and entry restrictions for untrained personnel. The sign is the first layer of that control: it tells anyone approaching the door that pressurized extinguishing agent is stored behind it.
The battery is also a maintenance object. Cylinders are periodically weighed or level-checked for agent loss, pilot lines and release mechanisms are tested, and bottles are pulled from the bank for hydrostatic retesting on a rotating schedule. Clear identification of the room supports permit-to-work routines and helps ensure service contractors, class surveyors, and crew all mean the same compartment when the maintenance plan says the battery is isolated or a section of it is out of service.
Placement and Supplementary Information
Post F008 on or beside the entrance to the cylinder space, at eye level where it will be read before the door is opened, and repeat it at any secondary access such as a hatch or escape trunk serving the same compartment. On larger vessels and plants, directional variants with arrows can guide responders along corridors or decks toward the battery, since the room is often tucked away from normal traffic routes and looks like any other store from the outside.
Supplementary text panels earn their place here more than on most fire signs. Stating the agent (CO2, nitrogen, argon blends), the spaces served, and the number of cylinders turns a generic location marker into actionable information for an arriving fire team deciding whether the system has fired and what remains available. Keep any added text consistent with the system schematic posted inside the room and with the vessel's or site's fire control plan, and update all three together after any modification to the bank.
Where you will see F008
On vessels with CO2 total-flooding protection for engine rooms or cargo spaces, the sign goes on the door of the dedicated cylinder room, visible to crew, port-state inspectors, and boarding firefighters. Ashore it marks gaseous-suppression cylinder rooms serving turbine enclosures, transformer vaults, archives, and data centers, often paired with asphyxiation warnings and ventilation-before-entry procedures because a leaking bank can displace the compartment's oxygen.
Common questions about F008
What does the ISO 7010 F008 sign mean?
F008 indicates the location of a fixed fire extinguishing battery — the bank of manifolded cylinders storing the agent for a fixed suppression system, such as a ship's CO2 room or a plant's inert gas cylinder space. It marks the agent storage, not the protected room or the release control.
What is the difference between F008 and F012?
F008 points to the cylinder battery where the extinguishing agent is stored. F012 marks a fixed fire extinguishing installation — generally the space that contains or is protected by the system. On a ship, the CO2 room door gets F008, while F012 relates to the installation itself.
Where should a fixed fire extinguishing battery sign be posted?
On or next to the door of the cylinder room, readable before anyone enters, plus directional versions along the route where the room sits away from normal circulation. Pairing it with the agent type and the spaces served helps fire teams act on it quickly.
Is a CO2 cylinder room dangerous to enter?
It can be. Leakage from cylinders or manifolds can displace oxygen in an enclosed battery room, so entry procedures commonly require ventilation checks and restrict access to trained personnel. The F008 sign identifies the space; asphyxiation warnings and entry controls address the hazard inside it.
Reference details
| Symbol code | F008 |
|---|---|
| Sign family | ISO Fire Equipment Signs |
| Standard reference | ISO 7010:2019 / ISO 3864-1 ISO Online Browsing Platform: F008 |
| Screen color reference | #FF0000. Screen colors are not a production color specification. |
| Download formats | SVG reference artwork; a 1024 × 1024 pixel PNG conversion on a white canvas. |
| Record date | · How to interpret our dates |
| Page updated |
Choosing a physical sign size
Download dimensions are not installation dimensions. Select sign size, material, placement, and lighting using the applicable standard and the actual viewing conditions. Chemical label sizing follows its own rules. Read the artwork and sizing guide.
