ISO F006 Fire emergency telephone Sign

A Telephone Reserved for Fire Emergencies

F006 pairs a telephone handset with a flame in the red square format, marking a telephone provided specifically for fire emergencies. Unlike an ordinary phone, the handset behind this sign connects directly to a point where a fire response can be initiated or coordinated — a fire control room, a permanently staffed security desk, or the building's fire alarm master station. Lifting it typically raises the far end automatically, with no number to dial and no risk of reaching voicemail.

The color is the fastest way to understand the sign's scope. ISO 7010 gives general emergency telephones the green safe-condition sign E004, while F006 sits in the red fire equipment family: this line exists for the fire system, not for summoning an ambulance or reporting a broken lift. Buildings that host both kinds of phone should sign them distinctly, because a caller under stress will grab whichever handset they find first.

Firefighter Telephones in Tall Buildings

The most common device behind an F006 sign is the firefighter telephone found in high-rise and large complex buildings. Modern fire alarm practice in many countries provides a wired emergency voice communication network — jack points or fixed handsets at fire service access points, in firefighting lobbies, stair landings, and lift machine spaces — so crews working deep inside a building can talk to the command point without depending on radio coverage through concrete and steel. In the UK this discipline is standardized in BS 5839-9; North American systems provide two-way telephone communication under fire alarm code provisions with a similar intent.

These stations are useless if crews cannot find them quickly in smoke-free early stages of an operation, which is where the signage does its work. An F006 marker at each handset or jack location lets a firefighter sweeping an unfamiliar lobby identify the communication point in seconds, and it discourages building occupants from treating the red handset cabinet as a general-purpose phone.

Refuge Points, Lift Lobbies, and Occupant-Facing Uses

Fire telephones are not only for responders. Refuge areas — the protected waiting spaces provided for people who cannot use stairs during an evacuation — commonly include a two-way communication terminal so the person waiting can confirm that someone knows where they are, and the control point can tell them help is coming. Similar intercom or telephone points appear in firefighting lift lobbies and at final exits on large sites where the assembly point is remote from the building.

For these occupant-facing installations, position F006 at the device and at the entrance to the refuge or lobby, mounted low enough to be legible from a wheelchair where that is the expected user. Pair the sign with brief operating instructions, because unlike an extinguisher or call point, a fire telephone's operation is not self-evident: some are hands-free intercoms, some are handsets in break-glass cabinets, and some are jacks that only fire crews carry handsets for.

What is a fire emergency telephone used for?

It provides a dedicated, direct voice link to the point managing a fire emergency, usually a fire control room or staffed alarm panel. Firefighters use them to coordinate operations inside large buildings where radios can be unreliable, and occupants use versions installed in refuge areas to tell the control point they are waiting for assistance.

How does the F006 sign differ from the E004 emergency telephone sign?

F006 is a red fire equipment sign marking a telephone dedicated to fire emergencies and connected to the fire response organization. E004 is a green safe-condition sign marking a general emergency telephone for summoning any kind of help. A building can legitimately display both, on different phones.

Where are fire telephones required in buildings?

Requirements come from national fire alarm and building codes rather than ISO 7010 itself, but typical locations are fire service access points, firefighting lobbies and stair landings in tall buildings, refuge areas for people unable to use stairs, and the fire control room end of each line. UK practice follows BS 5839-9 for emergency voice communication systems.

Do refuge area intercoms need the F006 sign?

They should be clearly marked, and F006 is the appropriate ISO symbol where the terminal is part of the fire emergency communication system. Because refuge users may be in wheelchairs, mount the sign and the device at an accessible height and add short instructions, since intercom operation varies between systems.
