Lifebuoy with line
Identifies a lifebuoy with a line.
Understanding this sign
Green square or rectangular signs identify emergency escape routes, safety facilities, and rescue equipment.
Follow the complete wayfinding system and local emergency plan. A symbol alone does not establish a safe route.
E041: A Buoy the Rescuer Can Pull Back
E041 identifies a lifebuoy fitted with a buoyant rescue line. The pictogram shows the ring with a rope trailing from it, distinguishing it from the bare buoy of E040. The line changes the nature of the rescue: instead of simply giving the casualty something to float on, it creates a physical connection between the person in the water and someone standing on solid ground.
That connection is decisive wherever the casualty would otherwise drift out of reach. In a river current, a harbour with wind across the basin, or a lock chamber with sheer walls, a floating ring without a line can carry the person away from help. A line-equipped buoy lets the thrower recover both the casualty and the equipment.
Shore-Based Rescue Technique
Line-equipped buoys are built for the throw stage of the classic reach-throw-row-go rescue progression, which keeps the rescuer out of the water for as long as possible. The rescuer secures or stands on the free end of the line, throws the ring past or beside the casualty, then hauls in steadily once the person has hold of it. Entering the water is the last resort, not the first response, and E041-marked stations exist precisely to make that last resort unnecessary.
This is why E041 stations dominate at quaysides, canal locks, ferry berths, and swimming pools: locations where an untrained bystander is the most likely first responder and pulling the casualty to a ladder or steps is the realistic outcome. Training the throw takes minutes; poolside staff and dock workers should practise it with the actual line length installed.
Line-Equipped Buoys Under SOLAS
The IMO Life-Saving Appliance Code requires ships to carry a minimum number of lifebuoys fitted with buoyant lifelines, positioned at least one on each side of the vessel, and specifies that the line must be long enough to reach the water from its stowage position with generous margin. A buoy whose line runs out before the ring hits the water is useless, so line length is calculated from the freeboard at the stowage point, not from a standard reel size.
Buoyant lifelines must also be non-kinking and are typically stowed coiled or figure-eighted so they pay out cleanly when thrown. E041 signage at these stations tells the crew which buoys can be used for a tethered recovery alongside, for example when retrieving a person from between the hull and a quay wall, where letting the buoy drift free would achieve nothing.
Signing Public Waterfronts Correctly
Local authorities and marina operators frequently install a mix of equipment along the same stretch of water: ring buoys with lines in cabinets, throw bags at kiosks, reach poles at pool edges. Post E041 only where the buoy genuinely has its line attached and serviceable. Public rescue equipment suffers heavily from vandalism and theft, and a missing or cut line silently converts an E041 station into an E040 one.
Inspection routines should therefore verify the line as well as the ring: present, correct length, free of rot and knots, and secured to the buoy. Pair the sign with brief use instructions where the expected rescuer is an untrained passer-by; a two-step graphic showing hold the end, throw the ring measurably improves correct first use.
Where you will see E041
Line-equipped buoy stations dominate at quaysides, canal locks, ferry berths, and swimming pools, where an untrained bystander is the likely first responder and pulling the casualty to a ladder is the realistic outcome. Under the IMO LSA Code ships carry buoys with buoyant lifelines on each side, with line length calculated from the freeboard, and public waterfront inspections must verify the line is present, sound, and attached, not just the ring.
Common questions about E041
How long should the line on a lifebuoy be?
Long enough to reach the water from the stowage position with margin to spare, which depends on the height of the quay, deck, or bridge above the waterline. Marine rules under the IMO LSA Code tie the minimum lifeline length to the stowage height. Ashore, waterfront operators typically size lines to the realistic throwing range at that location, often in the 25 to 30 metre region for open quaysides.
Is a throw bag the same as a lifebuoy with line?
No. A throw bag is a sack of floating rope with no buoyant ring; the casualty holds the rope itself while being pulled in. A lifebuoy with line gives the casualty substantial buoyancy to rest on during recovery, which matters for exhausted or injured people. Many public rescue stations stock both, and only the ring-plus-rope combination is correctly signed with E041.
When should I use E041 instead of E043?
Use E041 when the buoy carries a line but no light. E043 is reserved for stations where the buoy has both a buoyant line and a self-igniting light, a combination installed at critical points that must support rescue after dark. If your line-equipped station operates only in daylight hours, such as a seasonal pool, E041 is the accurate sign.
Do swimming pools need a lifebuoy with a line?
Requirements vary by jurisdiction and by whether the pool is supervised, but pool safety guidance commonly calls for reach or throw rescue aids appropriate to the pool size, and a ring buoy with line is a standard choice for larger or unsupervised pools. Whatever is installed, the signage should match the actual device so responders know what they are running toward.
Reference details
| Symbol code | E041 |
|---|---|
| Sign family | ISO Emergency Signs |
| Standard reference | ISO 7010:2019 / ISO 3864-1 ISO Online Browsing Platform: E041 |
| Screen color reference | #009933. Screen colors are not a production color specification. |
| Download formats | SVG reference artwork; a 1024 × 1024 pixel PNG conversion on a white canvas. |
| Record date | · How to interpret our dates |
| Page updated |
Choosing a physical sign size
Download dimensions are not installation dimensions. Select sign size, material, placement, and lighting using the applicable standard and the actual viewing conditions. Chemical label sizing follows its own rules. Read the artwork and sizing guide.
