Shipboard assembly station
Identifies a shipboard assembly station.
Understanding this sign
Green square or rectangular signs identify emergency escape routes, safety facilities, and rescue equipment.
Follow the complete wayfinding system and local emergency plan. A symbol alone does not establish a safe route.
What ISO 7010 E032 Identifies
E032 marks an assembly station on board a ship — the designated space where passengers and non-essential crew gather when the general emergency alarm sounds. The green square shows a group of figures beside a directional element, distinguishing it from the land-based E007 evacuation assembly point used at factories and building forecourts. In everyday maritime language the location is called a muster station; SOLAS and the sign's ISO referent use "assembly station" for the same place.
Assembly stations are chosen during the ship's design and approval: they must be near the survival craft embarkation positions, reachable from accommodation areas by protected escape routes, and large enough to hold their assigned complement wearing lifejackets. The sign fixes those decisions in the eyes of a passenger who has been on board for a few hours.
Muster Lists and the Station Bill
Behind every E032 sign sits paperwork required by SOLAS Chapter III. The muster list — called the station bill on many vessels — assigns each crew member an emergency duty and a station, and specifies which assembly station each cabin or passenger group reports to. Passengers meet their assigned station through the safety briefing and muster drill held before or immediately upon departure, a requirement tightened after modern passenger ship casualties showed how costly an unpracticed muster can be.
During an emergency the station is a control point, not just a waiting area. Crew assigned there take attendance against passenger manifests, distribute and check lifejackets, keep groups together, and hold everyone until the bridge either stands the ship down or orders embarkation into the survival craft. Reporting each station as closed up gives the master the headcount picture on which the abandonment decision depends, so the humble gathering place is genuinely part of the ship's command system.
Signing the Route, Not Just the Room
A single symbol at the station itself is never sufficient on a large vessel. E032 is combined with supplementary arrows along corridors, stairways, and open decks so that a disoriented passenger can follow an unbroken chain of signs from any cabin to the correct station. Stations are usually lettered or numbered on a supplementary panel — "Assembly Station B" — matching the designation printed on the cabin door safety plan and the boarding card.
Because musters may happen during a blackout or under smoke, the signs form part of the ship's low-location lighting and photoluminescent wayfinding system, mounted both at normal height and near the deck where visibility lasts longest. Cruise operators typically repeat the symbol on deck plans at every stair lobby, so a passenger checking their position against the plan sees the station marked with the same pictogram they will follow on deck.
E032 and Its Land-Based Counterpart
Facilities ashore should keep using E007 for evacuation assembly points; E032 exists specifically because a ship's muster serves a different purpose. Ashore, assembling means you have already escaped the hazard and are being counted. Afloat, there is nowhere to escape to — the station is a staging point for a possible transfer into lifeboats, liferafts, or a marine evacuation system, so it sits deliberately close to that equipment rather than far from the danger.
The related shipboard signs complete the sequence a passenger would follow: E031 where the alarm is raised, E032 where people gather, and the survival craft signs — E036 through E039, E054, and E055 — at the embarkation positions the station feeds. Auditors walking a passenger route expect that chain to be unbroken in both symbols and supplementary station identifiers, since a mismatch between the boarding card, the cabin plan, and the deck signage is precisely the confusion the system exists to prevent.
Where you will see E032
Cruise ships and passenger ferries post it at each station with lettered or numbered supplementary panels matching the cabin door safety plan and boarding card, and repeat it with arrows along corridors, stairways, and open decks so a disoriented passenger can follow an unbroken chain from any cabin. The signs form part of the low-location photoluminescent wayfinding system and recur on deck plans at every stair lobby, while cargo vessels sign their SOLAS muster stations the same way.
Common questions about E032
Is an assembly station the same as a muster station?
Yes. "Muster station" is the traditional shipboard term and "assembly station" is the wording used by SOLAS and the ISO 7010 E032 referent; they describe the same designated gathering place. Your boarding card, cabin door plan, and the deck signage all point to the same location.
What is the difference between E032 and E007?
E007 is the general evacuation assembly point sign used at workplaces and public buildings ashore. E032 is the shipboard version, marking a muster station that doubles as a staging area for boarding survival craft. On a vessel, use E032; on land, use E007.
What happens at an assembly station during an emergency?
Crew assigned to the station count passengers against the manifest, issue and check lifejackets, brief people on what is happening, and keep the group ready. Depending on the master's decision, everyone is then either released back to normal activities or led to the lifeboat, liferaft, or evacuation system embarkation points nearby.
How do I know which assembly station is mine on a cruise ship?
Your station letter or number is printed on your boarding card and on the safety plan inside your cabin door, and it is covered in the mandatory muster drill held before or as the ship departs. Corridor and stairway signs bearing the E032 symbol and your station designation lead you there.
Reference details
| Symbol code | E032 |
|---|---|
| Sign family | ISO Emergency Signs |
| Standard reference | ISO 7010:2019 / ISO 3864-1 ISO Online Browsing Platform: E032 |
| Screen color reference | #009933. Screen colors are not a production color specification. |
| Download formats | SVG reference artwork; a 1024 × 1024 pixel PNG conversion on a white canvas. |
| Record date | · How to interpret our dates |
| Page updated |
Choosing a physical sign size
Download dimensions are not installation dimensions. Select sign size, material, placement, and lighting using the applicable standard and the actual viewing conditions. Chemical label sizing follows its own rules. Read the artwork and sizing guide.
