Protection shelter
Identifies a protection shelter.
Understanding this sign
Green square or rectangular signs identify emergency escape routes, safety facilities, and rescue equipment.
Follow the complete wayfinding system and local emergency plan. A symbol alone does not establish a safe route.
A Safe-Condition Sign That Points Inward
Almost every sign in the ISO 7010 E-series moves people out of a building; E021 does the opposite. Its ISO register function is to indicate the location of a protection shelter — a hardened or enclosed space that people enter and remain in until a threat outside has passed. The pictogram sits on the standard green safe-condition square, so occupants read it with the same trust they give exit signs, but the instruction it carries is stay, not go.
That inversion matters during planning. Fire training conditions everyone to head for open air, yet tornadoes, toxic gas releases, armed threats, and mine emergencies all punish people who step outside. E021 gives the sheltering half of an emergency plan a standardized visual anchor, so the route to protection can be marked with the same rigor as the route to the door.
Where Protection Shelters Actually Exist
Civil defense infrastructure is the original home of this sign: countries such as Switzerland and Finland maintain extensive networks of public and residential blast shelters, and consistent marking is what makes a shelter findable by someone who has never visited the building before. Storm shelters are the other large civilian category — in the United States, tornado safe rooms and community storm shelters built to the ICC 500 storm shelter standard and FEMA safe-room guidance need equally unambiguous marking.
Industry adds its own variants. Underground mines provide refuge chambers stocked with breathable air, water, and supplies for miners cut off from the surface — US coal mines must provide refuge alternatives under MSHA rules — and chemical plants often designate shelter-in-place buildings with sealed ventilation for toxic release scenarios. In every case the shelter only works if workers can locate it quickly in darkness, dust, or panic.
Shelter or Evacuate: Marking Both Answers
Sites exposed to more than one hazard often need both responses available: evacuate for fire, shelter for tornado or gas. The signage system has to keep those instructions from blurring together. E021 marks the protective destination, while zone-warning signs for the natural hazard — tsunami, storm, or similar — mark where the danger applies, and distinct alarm tones tell occupants which plan is in effect at that moment.
Directional versions of the shelter sign, with supplementary arrows along the approach route, deserve the same attention normally reserved for exit routes. Add a text panel at the shelter door stating capacity and the shelter's identifier, and use photoluminescent or emergency-lit signs where storms or incidents are likely to cut power exactly when the shelter is needed.
E021 Versus the Assembly Point
E007, the assembly point sign, gathers evacuees in the open at a safe distance from the building. E021 does nearly the reverse: it brings people into an enclosed, protective structure. Posting the wrong one is not a cosmetic error — sending tornado-threatened staff to an outdoor muster area, or fire evacuees into a sealed room, defeats the plan entirely.
A practical rule: if the danger is the building, mark the way out and the E007 gathering point; if the danger is the environment or an airborne release, mark the way to E021. Training should rehearse both movements separately, because occupants under stress default to whichever drill they have practiced most recently.
Where you will see E021
Civil defense networks in countries like Switzerland and Finland mark public blast shelters with it, US communities apply it to ICC 500 tornado safe rooms, and underground mines use it for refuge chambers stocked with breathable air, water, and supplies. Chemical plants designate sealed shelter-in-place buildings for toxic release scenarios, adding directional arrows, capacity panels, and photoluminescent versions for power loss.
Common questions about E021
What does the ISO 7010 E021 protection shelter sign mean?
It marks the location of a protection shelter — an enclosed space designed to protect occupants from an external threat such as a tornado, toxic release, blast, or mine emergency. Unlike exit signs, it directs people to enter and remain inside until the danger has passed or rescue arrives.
What is the difference between a protection shelter and an assembly point?
An assembly point (E007) is the open-air spot where evacuees regroup once clear of the building, used when the building itself is the hazard. A protection shelter (E021) is an enclosed protective space used when the outside environment is the hazard — severe weather, airborne chemicals, or conflict. Many sites need both, marked distinctly and drilled separately.
Is there a standard sign for tornado or storm shelters?
ISO 7010 E021 is the international symbol for a protection shelter and is appropriate for tornado safe rooms and community storm shelters. In the United States, facilities often pair the symbol with text such as STORM SHELTER or SEVERE WEATHER SHELTER AREA, and shelters themselves are commonly built to the ICC 500 standard and FEMA safe-room guidance.
What sign marks a mine refuge chamber?
E021 is the ISO 7010 sign matching that function, since a refuge chamber is a protection shelter stocked with air, water, and supplies for miners who cannot reach the surface. Underground operations typically add high-visibility and photoluminescent route marking through the drifts, because a refuge chamber must be findable in smoke and total darkness.
Reference details
| Symbol code | E021 |
|---|---|
| Sign family | ISO Emergency Signs |
| Standard reference | ISO 7010:2019 / ISO 3864-1 ISO Online Browsing Platform: E021 |
| Screen color reference | #009933. Screen colors are not a production color specification. |
| Download formats | SVG reference artwork; a 1024 × 1024 pixel PNG conversion on a white canvas. |
| Record date | · How to interpret our dates |
| Page updated |
Choosing a physical sign size
Download dimensions are not installation dimensions. Select sign size, material, placement, and lighting using the applicable standard and the actual viewing conditions. Chemical label sizing follows its own rules. Read the artwork and sizing guide.
